OLED各尺寸展示板(2.42吋 128x64 電容式觸控OLED模組)

"OLED為新世代顯示器最新選擇，其優點/特色: 超輕薄。 自發光，無需背光模組。 超廣視角，幾乎無視角限制。 低耗電流。 超高亮度，高對比度。 反應速度快約10微秒左右 工作溫度範圍廣 OLED觸控顯示器被廣泛用在穿戴設備, 醫療設備，智能家用設備，智能控制設備，儀表設備或工控面板上。" "Winstar OLED modules are featured with all the important advantages – 。Thin – no need to have backlight, OLED emits light itself 。Wide view angle ""Up to 175 degree"" 。Lower power consumption 。High brightness 。High contrast ratio 。Fast response time 。Wide operation temperature The OLED touch display is widely used on wearable device, medical device, smart home device, intelligent technology device, meter device or industrial control panel."

PVTC-A1比容量測儀

封裝過程中，封裝材料的固化反應造成封裝體晶片相當程度的收縮與翹曲變形，為封裝體品質難以掌控的主因之一 本公司的比容量測儀是專業開發用來量測不同溫度、壓力等條件下材料固化過程比容的細微變化，提供資料¬¬準確預測封裝材料在封膠後的翹曲行為以提昇產品良率。 除外，本公司各式的架橋分析檢測儀也是專門量測用於穿戴電子產品、行動電子產或5G通訊設備之高分子材料固化反應的高精密儀器，歡迎與蔽公司聯絡。 榮獲台灣、美國、歐洲共同市場 發明專利 In semiconductor packaging industry, most numerical simulation of shrinkage would only consider the thermal effect of material. However, in many case study, the significant difference between simulation and reality is not only the value of deformation but also the trend of warpage. Analysis shows the cure-induced shrinkage of epoxy is the key. In those cases the effect of cure-induced are at the same level as the thermal effect. PVTC Analyzer can test the specific volume or volume change under various temperature and pressure to build up the relationship between volume and degree of cured.

減速機馬達

馬力從100W(1/8hp)到3700W(5hp)，採用輕量化鋁合金材質，外殼烤漆處理，外型美觀不易掉漆。透過精密加工，如陽減速馬達可表現低溫升、低噪音、低震動、不易漏油的特性。

齒輪箱

"減速機又稱為齒輪箱，透過內部多段齒輪設計，齒輪箱用於連結微型AC馬達或DC馬達減低輸出轉速、提高轉矩。 齒輪箱的外型簡單小巧、安裝容易，透過特殊齒輪設計與加工，強度高且使用壽命長，具有低噪音、不須更換油的優點。"

Ø1.18吋 電容式觸控 OLED 旋鈕Ø1.18" OLED Touch Encoder

WEO128128D型號為圓形OLED加CTP所推出的旋鈕樣式半成品，是一款有效區域直徑1.18吋，解析度128x128像素的COG OLED。此型號圓形OLED 非常適合需電容式觸控和旋鈕進行控制的產品項目使用，例如: 智能家居應用、智能技術設備、影音系統...等。 "The round OLED WEO128128D-CTP+Knob model is an extension item which equipped with capacitive touch screen and a control knob on module, it's an 1.18"" circular COG type OLED display; made of resolution 128x128 dots. This round OLED extended from WEO128128D model featured with capacitive touch screen and Knob is ideal for applications which required a control knob on devices such as smart home applications, intelligent technology devices, audio system, etc."

DC直流馬達

馬力規格從10W到250W，亦可選擇裝配齒輪箱，增加轉矩或降低轉速。產品外型簡單俐落、體積小、容易安裝，應用產業十分廣泛。

超音波加工刀把Ultrasonic Machining Tool Holder

"♦ 非接觸式電能傳輸系統允許高轉速、高精度先進材料加工 ♦ 隨插即用模組設計，擁有安裝便利性和靈活性 ♦ 超音波高頻率振動之高效率、高品質加工性能 ♦ 超音波振動降低切削阻力，有效延長刀具壽命 ♦ 開發高效智能自動追頻系統，適用於先進材料加工中各式刀具" "♦ High rotation speed for high precision advanced materials machining ♦ Plug and play installation convenience and flexibility ♦ High efficiency and high quality performance with the use of ultrasonic technology ♦ Effectively prolong tool life by reducing cutting resistance ♦ Suitable for special precise features demand in particular advanced materials ♦ Cost-effective intelligent tracking system for advanced materials machining"

華凌光電股份有限公司

漢鼎智慧科技股份有限公司

華凌光電股份有限公司

OLED產品簡介.mp4

中科形象影片

中科_管理局形象影片.mp4

如陽形象影片

中科_如陽形象影片.mp4

智慧型顯示器Smart display

"華凌標準品的顯示模組與內建的UI圖控物件，方便使用者直接用內建的韌體編碼可快速進行專案項目開發。 如果客戶需要客製UI圖控物件，華凌工程師團隊可以快速交付指定的新圖控物件。" "The Smart Display solution comes with Winstar standard display modules and UI objects to get customers project off the ground quickly. If customers need custom UI objects support, our engineers can send over a new set of UI objects quickly."

長型TFT顯示器

"長型TFT (Bar TFT)各適用於POS設備, 音響, 廣告儀器, 伺服器產品與博奕遊戲機等特殊尺寸應用。 目前推出尺寸有3.9吋, 4.6吋與5.2吋" "Bar Type TFT-LCD displays are perfect for industrial equipment, automotive application, server system, POS system, dynamic information displays and advertising display.   We offer different sizes Bar Type TFT including sizes of 3.9 inch, 4.6 inch and 5.2 inch. "

IPS TFT顯示器

"IPS面板視角廣度大，色彩鮮明、具有飽和自然的優質畫面。 IPS TFT除了視角廣還改善了TFT開口率，以產生更高的亮度，同時改善了色彩再現性。" "IPS TFT is a High Brightness wider view angle IPS TFT LCD module. The IPS TFT LCD Panel is becoming very popular because of featuring super wider viewing angle. It also improves the aperture ratio to produce higher brightness with improved color reproducibility."

PVT 熱塑性材料比容量測儀

熱塑性材料通常會因為壓力及溫度改變而有明顯的體積變化，進而使產品發生尺寸收縮與翹曲變形 本公司的比容測儀可提供材料之壓力-比容-溫度關係(PVT)，以便能計算材料在保壓階段時的可壓縮性，並能進一步提供資料預估產品於頂出之後收縮與翹曲情形。 1.According Standard:ISO 17744 2.Testing Method:Isothermal, Isobaric 3.Dimention:1935x910x590mm 4.Weight:约550kg 5.Temperature Control -Temperature Range:Room Temperature+5°~400℃ -Control Method:PID Control -Temperature Accuracy:±0.3℃ -Temperature Resolution:0.1℃ 6.Pressure Control -Force Transducer:25KN -Accuracy of Range:0.25% -Maximum Pressure:2500bar 7.Displacement Detector -Maximum Distance:60mm -Measuring Method:Optical Linear Encoder -Encoder Resolution:1um 8.Servo Motor Driving System -Minimum Displacement:0.12um -Speed Setting Range:0~1000mm/min 9.Diameter of Barrel & Piston:φ7.8mm 10.Cooling Method:Flow Control Air Cooling 11.Operator Interface:Touch Panel 12.Power Supply:AC220V,3phase,60Hz

優肯科技股份有限公司

UT-2080拉力測試機

1. 荷重：1,000 KGF 2. 主機搭配專用軟體提供自動資料分析 3. 多種夾具和荷重元可供選擇 4. 選擇附加之安全配備：保護檢視窗、安全回路系統、防護柵欄 5. 擁有多重測試功能，包含拉伸、壓縮、彎折、撕裂等多種測試項目，詳情請和我們聯繫。 1. Load capacity 1,000 kgf. 2. PC & Software provides automatic data analysis. 3. Various fixtures and load cells available. 4. Extended safety options: protective viewing window, electrical circuit safety system, protective fence. 5. Includes multiple testing functions. Please contact U-CAN for more details.

MDA-A1無轉子硫化儀

1.符合ISO 6502，ASTM D5289，DIN 53529，JIS K6300-2，和GB/T 16584之規範 2. 提供深入的焦燒及最佳硫化分析。 3. 針對混煉不佳的材料，提供可能原因的系統分析 4. 內含優肯新版操作軟體，更可選購(U-LIMS)藉由網路流覽器，設定測試條件及檢視結果`. 1. In compliance with ISO 6502, ASTM D5289, DIN 53529, JIS K6300-2, and GB/T 16584. 2. Moving Die Rheometer provides in-depth scorch and optimum cure time analysis. 3. Mis-compounding system advises of possible causes for failed compounds. 4. The latest version of U-CAN’s proprietary software is pre-installed. U-LIMS software is also available for purchase upon request, which allows users to set test conditions and view results remotely via an Internet browser. 5. Export to Excel.

超音波驅動模組 Ultrasonic Driver Module

"♦ 超音波數據即時輸出功能 ♦ 刀具適應性掃頻功能 ♦ 參數設定透明化 ♦ 驅動器功率（振幅）調整功能 ♦ 自動鎖頻功能 ♦ 多種控制方法：PLC、手動、Ethernet ♦ 支援單台驅動器對多數刀把" "♦ Cost-effective Solution Specialized in Advanced Materials Machining ♦ Immediate Ultrasonic Data Output ♦ Tool Adaptive Scanning ♦ Transparent Parameter Information ♦ Adjustable Power Level (Amplitude) ♦ Automatic Frequency-lock ♦ Multiple Control Modes: PLC, Manual, Ethernet ♦ One Driver for all Toolholders"

如陽科技股份有限公司

AC感應馬達

馬力從6W到150W，馬達體積小、噪音低、特性優異且容易安裝，亦可運用於連續運轉或正反運轉之情況，可廣泛用於各種機器動力用途。

MDA-A2自動送料機

1. 符合ISO 6502，ASTM D5289，DIN 53529，JIS K6300-2，和GB/T 16584之規範 2. 提供深入的焦燒及最佳流化分析 3. 針對混煉不佳的材料，提供可能原因的系統分析 4. 自動送料量選擇：120手、160手或240手料 5. 擁有測試膠片自動送料功能 6. 配置物聯網功能 1. In compliance with ISO 6502, ASTM D5289, DIN 53529, JIS K6300-2, and GB/T 16584. 2. Moving Die Rheometer provides in-depth scorch and optimum cure time analysis. 3. Mis-compounding system advises of possible causes for failed compounds. 4. The latest version of U-CAN’s proprietary software is pre-installed. U-LIMS software is also available for purchase upon request, which allows users to set test conditions and view results remotely via an Internet browser. 5. Export to Excel. 6. Auto feeding sampler.
