CI-BCR2:Twin-boring units- CNC Boring machine
CHI ING INDUSTRIAL CO., LTD.
Zhiying Company was established in 1981. Its main products are woodworking machines. In order to strengthen the competitiveness of its products, Zhiying Company persists in the idea of continuous improvement to introduce new concept and technology continuously and meet the customers’ requirements. The company’s operations team is composed of talents with a rich and diverse experience. It adheres to its values of professional skills, excellent customer service and sustainable operations in order to provide product consulting, after-sales service and technical support. The company’s products are well-recognized for its quality and the prices are reasonable to make it accessible to everyone. Zhiying Company aims to satisfy its customers and uphold the motto that customers’ satisfaction is the standard. Main products of Zhiying Industry Co., Ltd are: 1. Various woodworking machines (mortiser and chisel, air pressure type hinge machine, slotter and tenon machine, CNC router & CNC drilling machine, CNC 45° milling flute and tenon machine)
S510 CNC ROUTER with boring units
CHI ING INDUSTRIAL CO., LTD.
影片.mp4
S-TYPE
AC servo system : AC SERVO × 5 Ball screw size : X-axis : Helical Racks; Y-axis : 32MM Ball screw; Z-axis : 32 MM Ball screw Max. Speed : 80M/Min CNC controller : TAIWAN SYNTECPC-based CNC controller Spindle : ISO 30 8KW/Max.24000rpm ATC : 8 units carousel tool bank Vertical Drills Spindle : 5×5 on 32mm Tool length calibration : Automatic
CNC ROUTER
PRODUCTS Catalogs
COMET CNC ROUTER
Economical type
CNC ROUTER
CI-BCR2 CNC BORING CENTER
TWIN CLAMPING & BORING UNITS MAX.PANEL LENGTH : 3000mm MIN. PANEL LENGTH : 180mm MAX.PANEL WIDTH : 900mm MIN. PANEL WIDTH: 60mm MAX. PANEL THICKNESS : 80mm MIN. PANEL THICKNESS : 10mm RAPID POSITIONING : 60M/Min VERICAL SPINDLES : 11 units + 11 units HORIZONTAL SPINDLES : 8 + 8 units SPINDLE MOTOR 4.5KW MAX.18000rpm
boring machine
CI-BCR 5-SIDED CNC BORING MACHINE
VERTICAL SPINDLES: 8UNITS HORIZONTAL SPINDLES: X AXIS 2+2 / Y AXIS 1+1 NUMBER OF CONTROLLED AXIS: 4 (X-Y-Z-A) MAX BORING DEPTH: 40 mm MAX BORING DIAMETER: Ø35 mm GROOVING SAW DIMENSION: Ø110 mm
boring machine
